TM110019 - John Deere 7200R, 7215R, 7230R, 7260R, 7280R Tractors Diagnosis and Tests Service Manual

Illustrated Factory Diagnosis and Tests Service Manual for John Deere Tractors 7200R, 7215R, 7230R, 7260R and 7280R. Includes electrical wiring diagrams. Service Repair manual sold separate

This manual contains high quality images, circuit diagrams, diagnostic procedures to help you to diagnostic, troubleshoot and repair your truck. This document is printable, without restrictions, contains searchable text, bookmarks, crosslinks for easy navigation.

Language: English
Format: PDF, 6433 pages

Covered models (SN: 000101- 15200):
  7200R
  7215R
  7230R
  7260R
  7280R


Contents:


Foreword
   GENERAL
      Safety
      General References
   DIAGNOSTIC TROUBLE CODES
      Armrest Interface Control Unit (AIC)
      ActiveSeat™ Control Unit (ASU)
      Automatic Temperature Control Unit (ATC)
      Brakes System Control Software (BRC)
      Chassis Control Unit (CCU)
      Cab Load Center (CLC)
      Cab Suspension Control Unit (CSC)
      Cab Switch Module (CSM)
      Engine Control Unit (ECU)
      Engine Interface Control Unit (EIC)
      Front Console Control Unit (FCC)
      Hitch Control Unit (HCC)
      Hitch Valve (HV1)
      JDLink™ (JDL)
      Operator Interface Control Unit (OIC)
      Primary Display Unit (PDU)
      Front PTO Control Unit (PTF)
      AutoPowr™ / IVT™ Transmission Control Unit (PTI)
      PowrQuad™, AutoQuad™, and CommandQuad™ Transmission Control Unit (PTQ)
      Roof Lighting Control Unit (RLC)
      Rear PTO Control Unit (RPT)
      SCV Control Unit (SCC)
      Secondary Hydraulic Control Unit (SCO)
      Suspended Front Axle Control Unit (SFA)
      Sequence Control Unit (SMV)
      SCV I Control Unit (SV1)
      SCV II Control Unit (SV2)
      SCV III Control Unit (SV3)
      SCV IV Control Unit (SV4)
      SCV V Control Unit (SV5)
      SCV VI Control Unit (SV6)
      Front Hitch SCV Control Unit (SVJ)
      Mid-Stack SCV 1 Control Unit (SVK)
      Mid-Stack SCV 2 Control Unit (SVL)
      Mid-Stack SCV 3 Control Unit (SVM)
      Tractor Equipment Control Unit (TEC/TEI)
      AutoPowr™ / IVT™ Transmission Shift Control Unit (TII)
      PowrQuad™, AutoQuad™, CommandQuad™ Transmission Shift Control Unit (TIQ)
      Vehicle Load Center Control Unit (VLC)
      Virtual Terminal Implement Control Unit (VTI)
      ActiveCommand Steering (ACS™) A-Box Main Control Unit (XMA)
      ActiveCommand Steering (ACS™) B-Box Main Control Unit (XMB)
      AutoTrac™ Main Control Unit (XMC)
      ActiveCommand Steering (ACS™) A-Box Supervisor Control Unit (XSA)
      ActiveCommand Steering (ACS™) B-Box Supervisor Control Unit (XSB)
      AutoTrac™ Supervisor Control Unit (XSC)
   SYSTEM DIAGNOSIS
      Electrical
      Control Units
      Transmission
      Drive Systems
      Brakes
      Steering
      Hydraulics
      Suspension
      Operator Station
   ENGINES
      Theory of Operation
      Test and Adjustments
   FUEL AND AIR
      Theory of Operation
   ELECTRICAL
      General Information
      Electrical System Schematics
      Starting and Charging
      Road Lighting
      Field Lighting
      Interior Lighting
      ActiveSeat™
      Standard and Heated Seat
      Audible Alerts
      Windshield Wipers
      Operator Displays
      Cab Switch Module
      Remote Mirrors
      Radio
      Accessory Power Connectors
      PowrQuad-Plus™/AutoQuad-Plus™/CommandQuad™ Transmission
      AutoPowr™ / IVT™ Transmission
      Differential Lock
      MFWD
      PTO
      Front PTO
      Engines
      GreenStar™
      JDLink™
      Rear SCV`s and Rear Hitch
      Front Hitch and Midstack SCV`s
      Suspended Front Axle
      Cab Suspension
      Air Trailer Brakes
      Secondary Brakes
      Front Brakes
      HVAC (Manual)
      HVAC (Automatic)
      Steering
      Controller Area Network (CAN)
   CONTROL UNITS
      General References
      Calibration Procedures
      Control Unit Theory of Operation
      Control Unit Schematics
      Armrest Control Unit Tests
      Automatic Temperature Control Unit Tests
      Cab Control Unit Tests
      Cab Switch Module Control Unit Tests
      CommandCenter™ Control Unit Tests
      Corner Post Display Control Unit Tests
      Engine Control Unit Tests
      Front Chassis Control Unit Tests
      Power Assisted PTO Control Unit Tests
      Rear Chassis Control Unit Tests
      Roof Control Unit Tests
      Steering Control Units Tests
      Armrest Interface Control Unit (AIC)
      ActiveSeat™ Control Unit (ASU)
      Automatic Temperature Control Unit (ATC)
      Brake Control Unit (BRC)
      Chassis Control Unit (CCU)
      Cab Load Center (CLC)
      Cab Suspension Control Unit (CSC)
      Cab Switch Module (CSM)
      Engine Control Unit (ECU)
      Engine Interface Control Unit (EIC)
      Front Console Control Unit (FCC)
      Hitch Control Unit (HCC)
      Hitch Valve (HV1)
      JDLink™ (JDL)
      Operator Interface Control Unit (OIC)
      Power Assisted PTO Control Unit (PAP)
      Primary Display Unit (PDU)
      Front PTO Control Unit (PTF)
      AutoPowr™ / IVT™ Transmission Control Unit (PTI)
      PowrQuad™, AutoQuad™, and CommandQuad™ Transmission Control Unit (PTQ)
      Roof Lighting Control Unit (RLC)
      Rear PTO Control Unit (RPT)
      SCV Control Unit (SCC)
      Secondary Hydraulic Control Unit (SCO)
      Suspended Front Axle Control Unit (SFA)
      Sequence Control Unit (SMV)
      SCV Control Unit (SV1)
      SCV Control Unit (SV2)
      SCV Control Unit (SV3)
      SCV Control Unit (SV4)
      SCV Control Unit (SV5)
      SCV Control Unit (SV6)
      Front Hitch SCV Control Unit (SVJ)
      Mid-Stack SCV 1 Control Unit (SVK)
      Mid-Stack SCV 2 Control Unit (SVL)
      Mid-Stack SCV 3 Control Unit (SVM)
      Tractor Equipment Control Unit (TEC/TEI)
      AutoPowr™ / IVT™ Transmission Shift Control Unit (TII)
      PowrQuad™, AutoQuad™, and CommandQuad™ Transmission Shift Control Unit (TIQ)
      Vehicle Load Center Control Unit (VLC)
      Virtual Terminal Implement Control Unit (VTI)
      ActiveCommand Steering (ACS™) A-Box Main Control Unit (XMA)
      ActiveCommand Steering (ACS™) B-Box Main Control Unit (XMB)
      AutoTrac™ Main Control Unit (XMC)
      ActiveCommand Steering (ACS™) A-Box Supervisor Control Unit (XSA)
      ActiveCommand Steering (ACS™) B-Box Supervisor Control Unit (XSB)
      AutoTrac™ Supervisor Control Unit (XSC)
   ELECTRICAL CONNECTORS, WIRING HARNESSES, AND COMPONENTS
      Assemblies
      Sensors
      Lights, Various Devices, and Equipment
      Fuses (Protection Devices)
      Power Supply and Generators
      Monitoring Devices, Reporting Devices, and Signaling Devices
      Relays
      Motors
      Resistors
      Switches
      Diodes
      Wiring Harnesses
      Interconnects and Ground Points
      Electrically Actuated Mechanical Devices
   TRANSMISSIONS
      AutoPowr™ / IVT™ Preliminary and Operational Checks
      AutoPowr™ / IVT™ Theory of Operation
      AutoPowr™ / IVT™ Schematics and Diagrams
      AutoPowr™ / IVT™ Component Locations
      AutoPowr™ / IVT™ Tests and Adjustments
      PowrQuad Plus™ (PQ), AutoQuad Plus™ (AQ), and CommandQuad™ (CQ) Preliminary-Operational Checks
      PowrQuad Plus™ (PQ), AutoQuad Plus™ (AQ), and CommandQuad™ (CQ) Theory of Operation
      PowrQuad Plus™ (PQ), AutoQuad Plus™ (AQ), and CommandQuad™ (CQ) Schematics and Diagrams
      PowrQuad Plus™ (PQ), AutoQuad Plus™ (AQ), and CommandQuad™ (CQ) Component Locations
      PowrQuad Plus™ (PQ), AutoQuad Plus™ (AQ), and CommandQuad™ (CQ) Tests and Adjustments
   DRIVE SYSTEMS
      General References
      Axles and Differential Lock Preliminary and Operational Checks
      Axles and Differential Lock Theory of Operation
      Axles and Differential Lock Schematics and Diagrams
      Axles and Differential Lock Component Locations
      Axles and Differential Lock Test and Adjustments
      MFWD Preliminary and Operational Checks
      MFWD Theory of Operation
      MFWD Schematics and Diagrams
      MFWD Component Locations
      MFWD Tests and Adjustments
      PTO Preliminary and Operational Checks
      PTO Theory of Operation
      PTO Schematics and Diagrams
      PTO Component Locations
      PTO Tests and Adjustments
   BRAKES
      General References
      Preliminary and Operational Checks
      Theory of Operation
      Schematics and Diagrams
      Components
      Tests and Adjustments
   STEERING
      General References
      Preliminary and Operational Checks
      Theory of Operation
      Schematics and Diagrams
      Components
      Tests and Adjustments
   HYDRAULICS
      Preliminary and Operational Checks
      Theory of Operation
      Schematics and Diagrams
      Components
      Tests and Adjustments
   SUSPENSION SYSTEMS
      General References
      Suspended Front Axle Preliminary and Operational Checks
      Suspended Front Axle Theory of Operation
      Suspended Front Axle Schematics and Diagrams
      Suspended Front Axle Component Locations
      Suspended Front Axle Tests and Adjustments
      Cab Suspension Preliminary and Operational Checks
      Cab Suspension Theory of Operation
      Cab Suspension Schematics and Diagrams
      Cab Suspension Component Locations
      Cab Suspension Tests and Adjustments
   OPERATOR STATION
      HVAC Preliminary and Operational Checks
      HVAC Theory of Operation
      HVAC Component Locations
      HVAC Tests and Adjustments
      Seat Preliminary and Operational Checks
      Seat Theory of Operation
      Seat Schematics and Diagrams
      Seat Component Locations
      Seat Tests and Adjustments
   SERVICE TOOLS AND INSTALLING TEST EQUIPMENT
      Dealer Fabricated Tools
      Service Tools and Kits
      AutoPowr™ / IVT™ Transmission-Install Test Equipment
      PowrQuad Plus™ (PQ), AutoQuad Plus™ (AQ), and CommandQuad™ (CQ) Install Test Equipment
      Drive Systems-Install Test Equipment
      Brakes-Install Test Equipment
      Steering-Install Test Equipment
      Hydraulics-Install Test Equipment
      Suspension-Install Test Equipment
      Air Conditioning-Install Test Equipment
      Operator Seat-Install Test Equipment

Document
Document type	Diagnostic Manual
Covered
Type of Truck	7xxx Series Tractors
Models	7200R, 7215R, 7230R, 7260R, 7280R
