TM400519 - John Deere Tractors 6130, 6230, 6330, 6430, 6530, 6534, 6630 (European) Service Repair Manual

  • Brands: John Deere
  • Product Code: TM400519
  • Availability: In Stock
Illustrated Factory Repair Manual for John Deere 2WD or MFWD - European Tractors 6130, 6230, 6330, 6430, 6530, 6534 & 6630

This manual contains 3D animation video, high quality images, instructions to help you to operate, maintenance, diagnostic, and repair your truck. This document is printable, without restrictions, contains searchable text, bookmarks, crosslinks for easy navigation.

This is repair only manual, Diagnostic Manual with electrical wiring diagrams are sold separate.

Language: English
Format: ZIP, contained:
   PDF Manual, 2116 pages
   `VIDEO` folder

To view 3D animation you need to unpack PDF files and `VIDEO` folder in same folder on your harddrive. Also you need installed CATIA Composer Player, link to installer is included into PDF.

Covered models:
  6130
  6230
  6330
  6430
  6530
  6630
  6534


Contents:



Foreword
   Safety
      Safety Measures
   General Information
      Specifications
      Tests and Adjustments
      Predelivery Inspection
   Engine
      Removal and Installation of Components
   Fuel, Air Intake, Cooling and Exhaust System
      Removal and Installation of Components
      Speed Control
      Fuel System
      Air Intake System
      Cooling System
      Cold-Weather Starting Aids
      Exhaust System
   Electrical System
      Connector Information
      Charging Circuit
      Starting Circuit
      Electrical Components
   Electronic Control Units
      Removal and Installation of Electronic Control Units
      Removal and Installation of Terminating Resistors
   SyncroPlus Transmission
      Removal and Installation of Components
      Transmission Shift Units
      Perma Clutch II Module
      Gear-Shift Transmission
   PowrReverser Transmission
      Removal and Installation of Components
      Transmission Shift Units
      PowrReverser Module
      Gear-Shift Transmission
   PowrQuad Transmission
      Removal and Installation of Components
      Transmission Shift Unit
      PowrQuad Module
      Creeper Transmission
      Option Transmission
      Range Transmission
   Drive Train (without Transmission)
      Removal and Installation of Components
      U.J. Shaft and Torsion Damper
      Front-Wheel Drive Clutch
      Differential
      Differential - 3D Animation
      Hydraulic Pump Drive
      Final Drives
      Final Drives - 3D Animation
      Rear PTO
      Front Implement Drive
   Steering and Brakes
      Hydrostatic Steering
      Brake Valve
      Rear Brakes
      Handbrake
      Hydraulic Trailer Brake
      Air-Brake System
   Hydraulic System
      Operator Controls
      Oil Filter, Charge Pump and Hydraulic Pump
      Valves
      Hitch
      Selective Control Valves and Couplers
      Independent Control Valves (ICVs)
   Miscellaneous
      Removal and Installation of Components
      Main Frame
      Front Axle
      Front Wheels, Rear Wheels and Fenders
      Trailer Mounting and Swinging Drawbar
      Triple Link Suspension (TLS) of Front-Wheel Drive Axle
      Triple Link Suspension (TLS) of Front-Wheel Drive Axle - 3D Animation
      Pick-Up Hitch
   Operator′s Cab
      Removal and Installation of Components
      Controls and Instruments
      Air Conditioning System
      Heating System
      Seats
      Operator′s Cab
   Special Tools
      Special Tools (Dealer-Fabricated)
      Special Tools (Available as Spare Parts)
Document
Document type Repair Manual
Covered
Type of Truck 6xxx Series Tractors
Models 6130, 6230, 6330, 6430, 6530, 6534, 6630
Tags: 6130, 6230, 6330, 6430, 6530, 6534, 6630
