TM12351 - John Deere 130G (iT4/S3B) Excavator Service Repair Manual

Illustrated Factory Service Repair Manual for John Deere (iT4/S3B) Excavator 130G

This manual contains high quality images, instructions to help you to troubleshoot, and repair your truck. This document is printable, without restrictions, contains searchable text, bookmarks, crosslinks for easy navigation.

This is repair only manual, Diagnostic Manual with electrical wiring diagrams are sold separate.

Language: English
Format: PDF, 635 pages

Covered models (S.N. 1FF130GX__E040001):
  130G

Contents:

   Foreword
   Technical Information Feedback Form
   General Information
      Safety
      Torque Values
   Tracks
      Track System
   Axles, Differentials, and Suspension Systems
      Axle Shaft, Bearings, and Reduction Gears
      Hydraulic System
   Engine
      Removal and Installation
   Engine Auxiliary System
      Cooling Systems
      Intake System
      External Exhaust Systems
      External Fuel Supply Systems
   Damper Drive (Flex Coupling)
      Elements
   Frame or Supporting Structure
      Frame Installation
      Chassis Weights
   Operator`s Station
      Removal and Installation
      Operator Enclosure
      Seat and Seat Belt
      Heating and Air Conditioning
   Sheet Metal
      Hood and Engine Side Shields
   Excavator
      Buckets
      Frames
      Hydraulic System
   Swing or Pivoting System
      Mechanical Drive Elements
      Hydraulic System
   Dealer Fabricated Tools
      Dealer Fabricated Tools

Covered
Type of Truck	Crawler Excavator
