John Deere 2130 Tractors set of Service Manuals (TM4272)

Illustrated factory set of Technical Manuals for John Deere Tractors Models 2130.

This manuals will assist you in diagnosing, and repairing for your tractor.
You can use a Windows, Mac, or Android device to view this manuals. You only need to have a PDF reader installed.

Covered Models:
   2130

The manual comprises two Technical Manuals

1. Technical Manual: Hydrostatic Front Wheel Drive (tm4303)
Format: PDF, 113 pages
Language: English
Table of Contents:
   Description, Operation and Specifications
   Control System
   Hydraulic System
   Planetary Reduction Drive, Knuckle and Knee Assembly
   Diagnosing Malfunctions
   Front Wheel Drive Testing

2. Technical Manual (tm4272)
Format: PDF, 453 pages
Language: English
Publication Date: 01 Jan 1979
Table of Contents:
   GENERAL
      Specifications
      Pre- delivery, delivery and after-sales inspections
      Lubrication and periodic service
      Engine and tractor tune -up
      Tractor separation
   ENGINE
      General information, diagnosing malfunctions
      Cylinder head, camshaft and balancer shafts
      Cylinder block, liners , pistons and connecting rods
      Crankshaft, main bearings and flywheel
      Timing gear train
      Oil pump, oil pressure regulating valve, oil cooler and oil filter
      Engine cooling system
      Speed control linkage
   FUEL SYSTEM
      Diagnosing malfunctions
      Fuel tank, water trap, transfer pump, fuel filter and air cleaner
      Roto- Diesel fuel injection pump
      Fuel injection nozzles
      Cold weather starting aids
   ELECTRICAL SYSTEM
      Diagnosing malfunctions
      ’’Bilux” lighting system ( on earlier tractor models)
      ’ ’Bilux” lighting system ( on later tractor models)
      ’’Bilux” lighting system ( tractors with operator’s cab)
      Sealed-beam lighting system (on earlier tractor models)
      Sealed-beam lighting system (on later tractor models)
      Starting motor
      Alternator and regulator
   POWER TRAIN
      Engine clutches and clutch linkage
      High-Low shift unit
      Creeper transmission
      Collar-shift transmission
      Differential
      Final drives
      Independent pTO
   FRONT AXLE, STEERING SYSTEM AND BRAKES
      Front axle
      Steering system
      Hydraulic brakes
   HYDRAULIC SYSTEM
      General information, diagnosing malfunctions and pressure tests
      Oil reservoir, filter, valves and oil cooler
      Hydraulic pump and transmission oil pump
      Rockshaft
      Selective control valves (spool type)
      Selective control valves ( poppet valve type) and breakaway coupler
      Remote cylinder
   MISCELLANEOUS
      Belt pulley
      Seats
      Front and rear wheels
      Roll guard
      Operator’s cab ventilation and heating
      Operator’s cab

Covered
Models	2130
