TM802219 - John Deere 6165J, 6185J, 6205J, 6210J China Tractors Diagnostic Service Manual

Illustrated Factory Diagnostic and Tests Service Manual for John Deere 2WD or MFWD - China Tractors Models 6165J (6J-1654), 6185J (6J-1854), 6205J (6J-2054), 6210J (6J-2104)

This manual contains high quality images, circuit diagrams, instructions to help you to operate, maintenance, diagnostic, and repair your truck. This document is printable, without restrictions, contains searchable text, bookmarks, crosslinks for easy navigation.

Language: English
Format: PDF, 1632 pages

Covered models:
  6165J (6J-1654)
  6185J (6J-1854)
  6205J (6J-2054)
  6210J (6J-2104)

Contents:

Foreword
   General Information
      Safety Information
      General References
   Diagnostic Trouble Codes
      BCU Diagnostic Trouble Codes
      ECU Control Unit
   Observable Symptoms
      Electrical System
      Electronic Control Units
      PowrQuad Transmissions
      Drive Systems
      Steering and Brakes
      Hydraulic System
      Operator's Cab
   System Diagnosis
      Electronics
      Hydraulic System
   Engine
      General Information
      Operational Checks
      Tests and Adjustments
   Fuel, Air Intake and Cooling Systems
      Tests and Adjustments
      Fuel System
      Air Intake System
      Cooling System
      Cold-Weather Starting Aids
   Electrical System
      Fuse Box
      Starting and Charging Circuit
      CAN BUS and Service Connector
      ECU - Power
      ECU - Throttle and Fuel System
      ECU - Fuel Preheater and Aid Heater
      ECU - Sensors
      BCU - Electronic Hitch-Control
      BCU - Brakes
      BCU - PTO
      BCU - Front-Wheel Drive
      BCU - Differential Lock
      BCU - Hall Sending Unit Speedmeter
      BCU - Turn Signal and Hazard Warning Lights
      Panel Warning Lights
      Lights, Tail Lights and License Plate
      Work Lights
      Radio, Dome Light, Console Light and Beacon Light
      Horn and Accessories Socket
      Power Outlet
      Seat Compressor and Cigarette Lighter
      Fan and A/C
      Front Windshield Wiper and Washer
      Rear Windshield Wiper and Washer
      Trailer Connector
      Wiring Harnesses
      Connectors
   Electronic Control Units
      Operation and General Information on Diagnostics
      Interactive Tests
      Interactive Calibrations
      Information on How to Reprogram Control Units
      Data BUS Systems, Operation
      BCU - Basic Control Unit
      ECU Control Unit
   PowrQuad Transmissions
      Operational Check
      Tests and Adjustments
      Operation
      Range Box
   Drive Systems
      Operational Check
      Tests and Adjustments
      Operation
   Steering and Brakes
      Preliminary Checks
      Operational Check
      Tests and Adjustments
      Hydrostatic Steering
      Brakes
      Air brake system
   Hydraulic System
      Operational Check
      Tests and Adjustments
      Theory of operation
      Oil Filter, Charge Pump and Hydraulic Pump
      Hitch
      Selective control valves (SCV)
      Hydraulic block
   Operator's Cab
      Tests and Adjustments
      Operation
   Special Tools (Dealer-Fabricated)
      Special Tools (Dealer-Fabricated)
      Special Tools (Available as Spare Parts)

Document
Document type	Diagnostic Manual
Covered
Type of Truck	6xxx Series Tractors,China Tractors
Models	6165J, 6185J, 6205J, 6210J
